Square 90 Degree Elbow w/ Vanes - Stainless Steel
Square 90 Degree Elbow w/ Vanes - Stainless Steel
Couldn't load pickup availability
Optimize airflow in your residential HVAC system with the Square 90 Degree Elbow Duct with Vanes – Stainless Steel. Designed to improve air distribution in tight turns, this fitting reduces turbulence and static pressure so more of your conditioned air reaches each room. Ideal for DIY homeowners and small contractors, it integrates seamlessly into custom ductwork layouts and helps keep your system balanced and efficient.
Key Features
- High-quality stainless steel: Corrosion-resistant construction for long-lasting performance in home HVAC systems.
- Integrated airflow vanes: Redirects air smoothly through the 90° turn to minimize turbulence and reduce static pressure.
- Optimized for efficiency: Helps maintain consistent air velocity and volume, supporting even temperatures throughout the home.
- 16" leg lengths: Provides a precise fit for common rectangular duct runs in custom and retrofit installations.
- Built to SMACNA standards: Fabricated to professional HVAC guidelines for quality, reliability, and easy integration with other fittings.
- DIY-friendly: A smart upgrade for homeowners and small shops improving airflow, reducing noise, or updating older ductwork.
Product Specifications
| Material | Stainless steel |
| Configuration | Square 90° elbow with internal airflow vanes |
| Leg lengths | 16" each leg |
| Standards | Fabricated to SMACNA duct construction practices |
| Typical use | Residential and light commercial supply or return ductwork |
| Best for | Tight turns where smooth airflow and pressure control are critical |
Improve Airflow in Your Custom Duct Layout
In any rectangular duct system, sharp turns can become problem spots for noise, pressure loss, and uneven room temperatures. This stainless steel square elbow with duct vanes helps straighten the airflow through the 90° turn, reducing resistance so your air handler doesn’t have to work as hard. Use it when changing direction off a trunk line, feeding branches to rooms, or tightening up a mechanical room layout without sacrificing performance.
Build a Complete Stainless Duct System with Duct2Go
Pair this elbow with other made-to-order components from Duct2Go to keep your entire system consistent and efficient:
- Connect to matching fittings in our HVAC duct fittings collection for elbows, wyes, reducers, and take offs.
- Tie into straight runs of rectangular duct for clean, efficient supply and return trunks.
- Explore more corrosion-resistant options in our stainless steel ductwork collection to keep your system consistent from end to end.
Need a custom size or layout?
Duct2Go can fabricate custom elbows, transitions, and duct sections to match your exact HVAC design. Share your dimensions and project details and our team will help you dial in the right solution.
Request custom ductwork design & fabrication
